Engine Type |
5.3L 8 Cyl. Gas |
Horsepower |
355 @ 5600 rpm |
Torque |
383 @ 4100 rpm |
Type |
GAS |
Capacity |
26.0 Gallons |
Driven Wheels |
4 Wheel |
Vehicle Name |
Chevrolet Silverado 1500 N/A |
Body Style |
Crew Cab Pickup N/A |
Body Code |
E63 N/A |
Drivetrain |
Four Wheel Drive N/A |
Passenger Capacity |
5 N/A |
Gross Axle Wt Rating - Front |
3950 lbs |
Gross Axle Wt Rating - Rear |
3950 lbs |
Curb Weight - Front |
- TBD - lbs |
Curb Weight - Rear |
- TBD - lbs |
Fuel Economy Est-Combined |
17 MPG |
EPA Fuel Economy Est - City |
15 MPG |
EPA Fuel Economy Est - Hwy |
21 MPG |
Tons/yr of CO2 Emissions @ 15K mi/year |
10.3 N/A |
Gross Vehicle Weight Rating Cap |
7600 lbs |
Gross Combined Wt Rating |
17700 lbs |
Dead Weight Hitch - Max Trailer Wt. |
5000 lbs |
Dead Weight Hitch - Max Tongue Wt. |
500 lbs |
Wt Distributing Hitch - Max Trailer Wt. |
10800 lbs |
Wt Distributing Hitch - Max Tongue Wt. |
1080 lbs |
Fifth Wheel Hitch - Max Trailer Wt. |
- TBD - lbs |
Fifth Wheel Hitch - Max Tongue Wt. |
- TBD - lbs |
Maximum Trailering Capacity |
11700 lbs |
Engine Type |
Gas V8 N/A |
Fuel System |
Direct Injection N/A |
Engine Order Code |
L83 N/A |
Displacement |
5.3L/325 N/A |
SAE Net Horsepower @ RPM |
355 @ 5600 N/A |
SAE Net Torque @ RPM |
383 @ 4100 N/A |
Trans Order Code |
M5U N/A |
Trans Type |
8 N/A |
Trans Description Cont. |
Automatic N/A |
Trans Description Cont. Again |
N/A |
First Gear Ratio (:1) |
4.56 N/A |
Second Gear Ratio (:1) |
2.97 N/A |
Third Gear Ratio (:1) |
2.08 N/A |
Fourth Gear Ratio (:1) |
1.69 N/A |
Fifth Gear Ratio (:1) |
1.27 N/A |
Sixth Gear Ratio (:1) |
1.00 N/A |
Seventh Gear Ratio (:1) |
0.85 N/A |
Eighth Gear Ratio (:1) |
0.65 N/A |
Reverse Ratio (:1) |
3.82 N/A |
Clutch Size |
in |
Trans Power Take Off |
N/A |
Trans PTO Access |
N/A |
Transfer Case Model |
Magna MP3023/4 N/A |
Transfer Case Gear Ratio (:1), High |
1.00 N/A |
Transfer Case Gear Ratio (:1), Low |
2.69 N/A |
Transfer Case Power Take Off |
N/A |
Cold Cranking Amps @ 0° F (Primary) |
720 N/A |
Cold Cranking Amps @ 0° F (2nd) |
N/A |
Maximum Alternator Capacity (amps) |
150 N/A |
Maximum Alternator Watts |
N/A |
Total Cooling System Capacity |
15.6 qts |
Engine Oil Cooler |
Yes N/A |
Frame Type |
Hydroformed N/A |
Suspension Type - Front |
Independent N/A |
Suspension Type - Rear |
2-Stage Multi-Leaf N/A |
Spring Capacity - Front |
- TBD - lbs |
Spring Capacity - Rear |
- TBD - lbs |
Axle Type - Front |
- TBD - N/A |
Axle Type - Rear |
- TBD - N/A |
Axle Capacity - Front |
- TBD - lbs |
Axle Capacity - Rear |
- TBD - lbs |
Axle Ratio (:1) - Front |
3.23 N/A |
Axle Ratio (:1) - Rear |
3.23 N/A |
Shock Absorber Diameter - Front |
46 mm |
Shock Absorber Diameter - Rear |
35 mm |
Stabilizer Bar Diameter - Front |
1.35 in |
Stabilizer Bar Diameter - Rear |
in |
Front Tire Order Code |
RHH N/A |
Rear Tire Order Code |
RHH N/A |
Spare Tire Order Code |
RC4 N/A |
Front Tire Size |
P285/45R22 N/A |
Rear Tire Size |
P285/45R22 N/A |
Spare Tire Size |
P265/70R17 N/A |
Front Tire Capacity |
- TBD - lbs |
Rear Tire Capacity |
- TBD - lbs |
Spare Tire Capacity |
- TBD - lbs |
Revolutions/Mile @ 45 mph - Front |
- TBD - Rev/Mile |
Revolutions/Mile @ 45 mph - Rear |
- TBD - Rev/Mile |
Revolutions/Mile @ 45 mph - Spare |
- TBD - Rev/Mile |
Front Wheel Size |
22 x - TBD - in |
Rear Wheel Size |
22 x - TBD - in |
Spare Wheel Size |
17 x - TBD - in |
Front Wheel Material |
Aluminum N/A |
Rear Wheel Material |
Aluminum N/A |
Spare Wheel Material |
Steel N/A |
Steering Type |
Electric Rack & Pinion N/A |
Steering Ratio (:1), On Center |
16.3 N/A |
Steering Ratio (:1), At Lock |
- TBD - N/A |
Turning Diameter - Curb to Curb |
47.2 ft |
Turning Diameter - Wall to Wall |
- TBD - ft |
Brake Type |
Pwr N/A |
Brake ABS System |
4-Wheel N/A |
Brake ABS System (Second Line) |
N/A |
Disc - Front (Yes or ) |
Yes N/A |
Disc - Rear (Yes or ) |
Yes N/A |
Front Brake Rotor Diam x Thickness |
13.0 x 1.18 in |
Rear Brake Rotor Diam x Thickness |
13.6 x 0.79 in |
Drum - Rear (Yes or ) |
N/A |
Rear Drum Diam x Width |
in |
Fuel Tank Capacity, Approx |
26 gal |
Aux Fuel Tank Capacity, Approx |
gal |
Fuel Tank Location |
- TBD - N/A |
Aux Fuel Tank Location |
N/A |
Front Head Room |
42.80 in |
Front Leg Room |
45.27 in |
Front Shoulder Room |
66.03 in |
Front Hip Room |
60.73 in |
Second Head Room |
40.50 in |
Second Leg Room |
40.93 in |
Second Shoulder Room |
65.73 in |
Second Hip Room |
60.27 in |
Wheelbase |
143.5 in |
Length, Overall w/o rear bumper |
230.03 in |
Width, Max w/o mirrors |
80.0 in |
Height, Overall |
73.97 in |
Overhang, Front |
- TBD - in |
Overhang, Rear w/o bumper |
- TBD - in |
Front Bumper to Back of Cab |
150.90 in |
Cab to Axle |
31.97 in |
Cab to End of Frame |
- TBD - in |
Ground to Top of Load Floor |
34.3 in |
Ground to Top of Frame |
- TBD - in |
Frame Width, Rear |
- TBD - in |
Ground Clearance, Front |
8.90 in |
Ground Clearance, Rear |
8.90 in |
Cargo Box Length @ Floor |
69.33 in |
Cargo Box Width @ Top, Rear |
- TBD - in |
Cargo Box Width @ Floor |
64.6 in |
Cargo Box Width @ Wheelhousings |
51.03 in |
Cargo Box (Area) Height |
21.10 in |
Tailgate Width |
62.2 in |
Cargo Volume |
53.4 ft³ |
Ext'd Cab Cargo Volume |
- TBD - ft³ |
Gross Vehicle Weight |
6,001 lbs |
